SC-USB-03
Waterproof On-Board Charging,
Whatever The Weather.
ROKK Charge Pro is the ultimate onboard USB charger. Featuring a USB-A and USB-C charging port housed in an IPX6 waterproof design, this is the only USB-C charger on the market that remains waterproof while in use.
Product Information.
Say hello to fast charging! The unique design charges up to 36W on 12V systems and 60W on 24V systems. This makes it ideal for charging modern laptops via the USB-C port. It's also twice as fast when charging larger tablets, designed to easily charge an iPad Pro and iPhone at the same time.
Perfect for where space is at a premium, ROKK Charge Pro has a sleek, ultra-compact design with a click-and-lock lid allowing the USB to remain waterproof while in use. Constructed from premium, marine-grade materials, ROKK Charge Pro is IPX6 waterproof making it completely wash-down ready.
USB – C output:
60W max on 24V system
36W max on 12V system
USB – A output:
36W max
The install cut-out matches those of standard USB sockets for easy retrofit or swap of an existing USB charger, allowing you to keep up with the heavier power draws of modern electronic devices.
Universal
• Universal fit for any USB-A or USB-C connectors.
• Fast charge (60W max) up to 2 devices at a time.
• Easy Install, using standard USB mounting hole - 29mm (1 1/8”)
Washdown Proof
IPX6 waterproof with the lid closed.
Marine Ready
• Anti-corrosion coating on the circuit board.
• UV resistant.
• 316 stainless hinge and spring.
Electrical Information
- Input voltage: 10-30V DC (12/24V System)
- Input current Max: 6A (10A fuse recommended)
- Standby power draw: 0.01W
Important information
The charge cable supplied with your device (tablet, phone, action camera, etc) must be used to achieve maximum charge performance from this charger. Phones will charge at the same speed whether on a 12V or 24V input voltage system. However, a 24V system must be used to get the full 60W output suitable for fast-charging laptops.
Our Testing Ethos
Our testing standard at Scanstrut is encapsulated by the acronym SCA, which stands for Safe, Certified, and Approved. With over 35 years of experience and expertise in designing products for outdoor use, we design our products to be able to thrive in the harshest of outdoor environments.
Before any product is released, it must pass through our rigorous testing program which involves assessments in electrical, mechanical, U.V., corrosion, thermal, and waterproof categories. To ensure the highest level of accuracy, testing is conducted both internally and by independent ISO accredited test houses.
Our commitment to quality has earned us the approval of renowned names such as Mercury Marine, Grady White Boats, Boston Whaler, Winnebago, Airstream and many more. To learn more about our testing program and certifications, please feel free to reach out to us.
SC-USB-01
- IPX4 waterproof rating
- Waterproof with 1, 2 or even 0 cables plugged
- The socket will work with any USB Type-A connector
- Standard barrel size also fits existing USB sockets.
ROKK Charge+
- IPX6 waterproof rating
- Featuring 2x USB-A charging ports
- Fast charge
- Waterproof with 1, 2 and even no cables plugged in.
- Ultra low profile
ROKK Charge/Sync Cable
- Available in two durable lengths; 60cm or 2M
- Apple Lightning or Micro USB connector options
- All models feature a high-spec core that ensures super-fast charge/sync
What makes ROKK charge + up to 3x faster than other USB sockets?
The PCB (printed circuit board) inside the ROKK Charge+ enables the device to recive similar charge as it would from a mains power charger.
Why is the Scanstrut charge range different to other so called "waterproof USB chargers" on the market?
Our range of USB chargers remains waterproof even when the socket is in use. Other USB chargers are only waterproof when not being used and the cover fitted.
Can I replace an old USB socket with a Scanstrut version?
In most case it’s an easy swap, just remove the old version and our USB barrels will fit into th existing hole and add self tapping screw/s where required.
